Description
High density, double-conversion on-line power protection with scalable runtime.
– Generator compatible
– Cold-start capable
– Power conditioning
– Frequency and voltage regulation
– 208/240V to 120V Step-Down Transformer
– Resettable circuit breaker
– Safety-agency approved
– Network manageable
– Low operating and maintenance costs with proven reliability and intelligent battery management
– Avoids costly power problems by keeping your IT equipment and data protected and available
– Peace of mind that comes with full equipment compatibility and reliability of a leader
– Save time with easy and convenient remote accessibility
Specifications
| Power | |
|---|---|
| Output power capacity | 5 kVA |
| Output power | 4.25 W |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 275 V |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 208 V |
| Surge energy rating | 480 J |
| Efficiency | 93.4% |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Output frequency | 50/60 Hz |
| Input frequency | 40 – 70 Hz |
| Ports & interfaces | |
| Cable length | 120.1″ (3.05 m) |
| AC outlets quantity | 15 AC outlet(s) |
| AC outlet types | NEMA L5-20R, NEMA L6-20R, NEMA L6-30R |
| Power plug | NEMA L6-30P |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 3 |
| Performance | |
| UPS topology | Double-conversion (Online) |
| Surge protection | Yes |
| Waveform | Sine |
| Power protection features | Overload |
| Auto-restart | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| Noise level | 55 dB |
| LED indicators | Battery replacement |
| Audible alarm(s) | Yes |
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 4.25 W |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 275 V |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 208 V |
| Surge energy rating | 480 J |
| Efficiency | 93.4% |
| Surge protection | Yes |
| Emergency Power Off (EPO) | Yes |
| Waveform | Sine |
| Power protection features | Overload |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Output frequency | 50/60 Hz |
| Auto-restart | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Input frequency | 40 – 70 Hz |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 1.5 h |
| Typical backup time at half load | 14 min |
| Typical backup time at full load | 5 min |
| Hot-swap battery | Yes |
| Cold start | Yes |
| Battery capacity | 840 Ah |
| Automatic battery test | Yes |
| Design | |
| Form factor | Rackmount/Tower |
| Rack capacity | 5U |
| Product colour | Black |
| International Protection (IP) code | IP20 |
| Cable length | 120.1″ (3.05 m) |
| LED indicators | Battery replacement |
| Housing material | Steel |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| Operating altitude | 0 – 118110.2″ (0 – 3000 m) |
| Technical details | |
| Output frequency | 50/60 Hz |
| Sustainability certificates | ENERGY STAR |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 17″ (432 mm) |
| Depth | 28.3″ (719 mm) |
| Height | 8.58″ (218 mm) |
| Weight | 218 lbs (98.9 kg) |
| Package width | 24.5″ (622 mm) |
| Package depth | 37.8″ (960 mm) |
| Package height | 23″ (584 mm) |
| Package weight | 259.9 lbs (117.9 kg) |
| Packaging data | |
| Quick installation guide | Yes |
| Cables included | USB cable |
| Resource CD | Yes |
| Rack mount kit | Yes |
| Bracket | Yes |
| Package width | 24.5″ (622 mm) |
| Package depth | 37.8″ (960 mm) |
| Package height | 23″ (584 mm) |
| Package weight | 259.9 lbs (117.9 kg) |
| Logistics data | |
| Products per pallet | 3 pc(s) |
| Packaging content | |
| Quick installation guide | Yes |
| Cables included | USB cable |
| Resource CD | Yes |
| Rack mount kit | Yes |
| Bracket | Yes |
